Marin San Rafael DS1

Marin San Rafael DS1
  • Color: Gloss Black/Silver
This item is currently not available.

Details

The San Rafael is for riders looking to explore mixed surfaces and terrain, travel the local rail-trail system, and explore paved paths and dirt doubletrack equally at home. Dual Sport bikes are a bridge between pavement and dirt, making them perfect for the adventurous fitness and recreational rider.

Serie 2 Aluminum Frame
The San Rafael and San Anselmo have a Series 2 6061 butted and hydroformed aluminum frame with disc brakes, rear rack and fender mounts, a 63mm travel suspension fork, and 700C wheels

Disc Brakes
Hydraulic disc brakes provide smooth, controlled stopping in all conditions with minimal maintenance.

- Series 2 aluminum frame
- SR Suntour NEX fork w/63mm of travel
- Shimano 2x7 drivetrain
- Power CX7 mechanical disc brakes

Specs

Frame Series 2 Dual Sport, 6061 Aluminum, 700C Wheels, Disc Brake
Fork SR Suntour NEX, 63mm Travel, Preload Adjustment
Headset FSA No.10-P
Rims/Wheels Marin Aluminum Double Wall
Hubs Forged Aluminum Alloy, 32H
Spokes 14g Stainless Steel
Tires Kenda Kahn, 700c x 40
Crankset Forged Alloy Crank, w/Ring Guard
Chainrings 46/30T
Bottom Bracket Sealed Cartridge Bearings, Square Taper
Chain KMC Z8
Front Derailleur Shimano TY710
Rear Derailleur Shimano Tourney, 7-Speed
Cassette/Rear Cogs SunRace 7-Speed, 11-34T
Shifters Shimano EF500 Shifter/Brake Lever Combo, 2x7-Speed
Handlebars Marin Alloy Riser
Tape/Grips Dual Density Ergonomic
Stem Marin Alloy, 31.8mm Clamp
Brake Levers Shimano w/ Integrated Shifters
Brakes Power CX7 Mechanical Disc, Shimano Pad Compatible, 160mm Rotors
Pedals Dual Sport Platform
Saddle Marin Fitness Plush
Seat Post Marin Alloy, 27.2mm

* Subject to change without notice.

Videos

2020 Marin Dual Sport

Part Numbers

Option UPC MPN
Gloss Black/Silver / X-Small 843346107848 732418001
Gloss Black/Silver / Small 843346107855 732418002
Gloss Black/Silver / Medium 843346107862 732418003
Gloss Black/Silver / Large 843346107879 732418004
Gloss Black/Silver / X-Large 843346107886 732418005
